55W (182 cells)
SiNx AR Coating
n+ emmitter
p-Silicon substrate
rear Passivation
SiNx AR Coating
PERC PV Module
SiNx AR Coating
n+ emmitter
p-Silicon substrate
rear Passivation
SiNx AR Coating
High Efficiency for PERC PV Module Series(182/210)
SiNx AR Coating
n+ emmitter
p-Silicon substrate
rear Passivation
SiNx AR Coating
182 & 210mm wafer
A+ Grade Solar Cell as Tier 1
Lossless Scribing
Non-destructive scribing technology, no mechanical damage
Smooth cutting surface without burrs
The risk of cell cracks is low, and micro cracks are reduced by more than 50%
Multiple Busbars
Dense grid lines, uniform force, multi-busbar design
The output power is increased by more than 5W
Encapsulation High-density technology
Minimized space between cells to cells to improve module effciency 0.2-0.3%
Excellent Mechanical Load
Positive mechanical load up to 5400Pa
Negative mechanical load up to 2400Pa
Better frame design for PV Module
Thicker frame prole
Stronger material strength
Larger frame chamber to disperse loading pressure
| 55W (182 cells) | ||
| Max. Power at STC | Pmax | 55W |
| Optimum Operating Voltage | Vmp | 18.40V |
| Optimum Operating Current | Imp | 2.99A |
| Open Circuit Voltage | Voc | 21.60V |
| Short Circuit Current | Isc | 3.17A |
| Dimensions | 430x768x25mm | |
| Weight | 3.7kg | |
Discover our high-performance 55W Solar Panel with 182 cells, engineered for residential, commercial, and off-grid solar applications. Part of our PERC PV Module Series， this module combines advanced PERC technology with durable materials to ensure high energy conversion, long-term stability, and reliable output.
Our 55W PERC PV Module with 182 cells delivers high efficiency, reliability, and long-term durability, ideal for residential rooftops, commercial installations, and off-grid energy solutions. With advanced PERC technology, multi-busbar design, and high-quality Tier 1 solar cells, it ensures consistent energy performance and dependable output.
Explore more options in our full PERC PV Module Series to find panels suitable for different power needs.
